Frequency (MHZ) |
Attenuation (Db) |
Characteristic impedance (〇) |
Near-end crosstalk attenuation (minimum dB) |
Return loss (minimum dB) |
|
1 |
2 |
100±15 |
65.3 |
20 |
|
4 |
4.1 |
100±15 |
56.3 |
23 |
|
8 |
5.8 |
100±15 |
51.8 |
24.5 |
|
10 |
6.5 |
100±15 |
50.8 |
25 |
|
16 |
8.2 |
100±15 |
47.3 |
25 |
|
20 |
9.3 |
100±15 |
45.8 |
25 |
|
25 |
10.4 |
100±15 |
44.3 |
24.3 |
|
31.25 |
11.8 |
100±15 |
42.9 |
23.6 |
|
62.5 |
17.1 |
100±15 |
38.4 |
21.5 |
|
100 |
22 |
100±15 |
35.3 |
20.1 |
